Description
Easy to use machine to increase efficiency and productivity for the light manufacturing and fabrication users. Color screen featuring Auto-Set™ Elite and Pulsed MIG. This all-in-one welder connects to 208 or 240 volt input power. Welds up to 1/2” aluminum, stainless and mild steel.
GENERAL SPECIFICATIONS
| Title | Millermatic® 255 MIG/Pulsed MIG Welder w/ EZ-Latch™ Running Gear- 208/240V |
| Material Thickness | Aluminum 18 ga. (1.02 mm) – 1/2 (13mm) Mild Steel 24 ga. (.51 mm) – 1/2 (13mm) |
| Weldable Metals | Aluminum Stainless Steel Steel |
| Input Voltage | 208 V 220/230/240 V |
| Input Phase | 1-Phase |
| Input Hz | 60 Hz |
| Input Amperage | 20-350 |
| Current Type | DC |
| Rated Output | 230 A at 25.5 V, 60% duty cycle |
| Max Open Circuit Voltage | 87 VDC |
| Wire Feed Speed | 50 IPM – 800 IPM |
| Wire Diameter | Aluminum 0.035 in 0.047 in Flux Cored 0.03 in 0.045 in Stainless 0.023 in 0.045 in Solid Steel 0.023 in 0.045 in |
| Spool Size | 12 in (305 mm) |
| Portability | Handle(s) Running Gear / Cart (Standard) |
| Weld Output | CV |
| Warranty | 3 Years Miller’s True Blue Warranty |
